CASEA bauprocalc 830 – Hydraulic Lime Based Render
bauprocalc 830 is a CE-marked, factory-produced hydraulic hardening render/plaster based on lime, specially designed for hand and machine application produced to DIN EN 998-1.
bauprocalc is an excellent alternative to plaster and renders containing gypsum or patent cement which have less vapour permeable qualities.
It is manufactured from a controlled blend of selected aggregates, hydraulic and building lime to EN 459-1, and other components to give a high-quality rendering product suitable for use in external rendering and internal plastering. The unique properties of this render make it suitable for application on low, medium, and high-density substrates, for the renovation of old / listed buildings and ecological new builds.
bauprocalc 830 has unique properties, making it suitable for application on low, medium, and high-density substrates, especially suited for renovating old /listed buildings and ecological new builds. Good vapour permeability performance allows an unhindered transference of excess internal moisture through the building to the outside, thereby contributing significantly to a balanced and healthy internal atmosphere.
bauprocalc 830 contributes to a healthy internal atmosphere. It’s an excellent alternative to plasters containing gypsum or patent types of cement which have reduced vapour-permeable qualities. It’s ideal for kitchens, bathrooms, and other rooms where high humidity levels are expected.
It is manufactured from a controlled blend of selected aggregates, hydraulic and building lime to EN 459-1 and other components to a high-quality rendering product which is suitable for use in external rendering and internal plastering.
bauporcalc 830 hydraulic lime-based render, produces a mortar that is softer than cement mortar, excellent for the renovation of old /listed buildings and ecological new builds.
After the initial set, stability and strength gradually build up over time; allowing enough flexibility to cope with minor settlement or movement in the building during this period, thereby reducing the risk of cracking. Good vapour permeability performance allows an unhindered transference of excess internal moisture through the building to the outside, thereby contributing significantly to a balanced and healthy internal atmosphere.
Related Downloads
TDS CASEA Bauprocalc 830 – Hydraulic Lime Based Render
Application Guide CASEA Bauprocalc 830
EPD CASEA Bauprocalc 830 – Hydraulic Lime Based Render
Benefits of CASEA bauprocalc 830 – Hydraulic Lime-Based Render
• High water vapour permeability (breathability)
• Machine or Hand Application
• Suitable for external and internal use
• Sustainable
• Application up to 15 mm
• DIN EN 998-1
Technical Details for CASEA bauprocalc 830 – Hydraulic Lime-Based Render
| Dry Bulk Density | 1300 kg/m³ |
| Compressive Strength | >2.0 N/mm² |
| Adhesion | ≥ 0.08 N/mm² FP: A, B or C |
| Flexural Strength | >1.0 N/mm² |
| Modulus of Elasticity | approx. 6 kN/mm² |
| Grain size | 0-1 mm |
| Water Vapour Permeability | μ ≤ 20 |
| Thermal Conductivity | λ10, dry,mat ≤ 0.82 W/(mK) @ P=50% λ10, dry,mat ≤ 0.89 W/(mK) @ P=90% |
| Yield | approx. 830 l/t approx. 55 m² at 15 mm applied thickness approx. 2 m² per 30 kg bag |
| Water Demand | 7.5 l per 30 kg bag |
| Reaction To Fire | A1 Non-Combustible |
Available in 30kg bags.
Call SMET to purchase directly:
Check out SMET’s sustainable range of lime and lime-based products, currently available from Smet Building Products Ltd.
NHL binders
To purchase pure natural SMET NHL binders, you can buy SMET NHL 3.5 direct from Haldane Fisher Nationwide, by following this link. SMET NHL binders, available online or in-store via our distribution partner Haldane Fisher. SMET NHL binders are particularly suited for ecological new builds, conservation, restoration, and preservation works. The products’ special composition allows mortars to breathe and permits constant hygrometric exchange between the substrate and the environment.
